Our filter bag cages are carefully constructed to each individual’s specific requirement. Custom designed proprietary machinery allows us to solve intricate wire forming and welding problems while producing part at a competitive price.
We provide a wide range of configuration to best fulfill your needs. Cage constructions consist of 8, 10, 12, or 20 vertical wires. Customized ring spacing standard is 6” or 8”
(5.24cm 20.32cm)
Cage diameters range from 4” to 8” (100mm to 200mm)
Wire thickness ranges are 11 gauge to 8 gauge (3.00mm to 4.00mm)
Our state of the art machinery can produce 30 lengths of 4000mm filter cage per hour. We offer two-piece cage for application in low headroom situation, where access is a problem. This style can make for easier installation and removal in these difficult applications
We have different type of cage top. Some of the types are as follows:-
a.
Roll band low groove
b.
Straight flange
c.
Roll flange with build –in venturi
d.
Roll flange top with two piece body design
e.
Roll flange high groove, two piece cage
We are offering two pieces cage for application with low headroom. This can be made for easier installation and removal in these difficult applications
Below are some of the specifications required to provide a quotation on your filter bag cage:
1.
Wire gauge or diameter of vertical wires and rings
2.
Quantity of vertical wires (i.e. 8,10,12,20)
3.
Spacing required between rings
4.
Quantity and diameter of rings
5.
Overall length of cage
6.
Type of material required
7.
Type of finish
8.
Type of collar
9.
Type of bottom cap
10.
We provide ventury for your cage too
Our production line produced 30-40 length of 4000mm filter cage per hour for 10 vertical wires.
